The ASBVIC205 counting module delivers precise pulse counting for Modicon TSX COMPACT automation platforms. Schneider Electric designed this four-channel input module to handle high-speed signals in demanding industrial environments. Engineers rely on its stable performance for material handling, packaging, and textile machine applications.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model | ASBVIC205 |
| Product Line | TSX COMPACT |
| Category | Counting Module |
| Number of Channels | 4 |
| Input Voltage | 5 VDC |
| Input Type | TTL high-speed pulse |
| Maximum Frequency | 25 kHz |
| Protection Class | IP20 |
| Enclosure Rating | NEMA 1 |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 80% RH, non-condensing |
| Maximum Altitude | 1000 m above sea level |
| Certifications | CE, UL, RoHS |
Key Features and Benefits
This module accepts four independent high-speed pulse inputs with 5V TTL compatibility. Consequently, it processes signals up to 25 kHz without losing count accuracy. The IP20 protection rating safeguards internal components from dust and contaminants in controlled environments.
Additionally, the ASBVIC205 integrates seamlessly with existing TSX COMPACT racks. Its compact form factor reduces panel space requirements while maintaining full functionality. The NEMA 1 enclosure rating suits indoor installations in mild industrial conditions.
Applications and Compatibility
This counting module excels in flow measurement and positive displacement monitoring tasks. It connects directly to flow meters, encoders, and other pulse-generating devices. Furthermore, the module supports material handling systems, packaging lines, and textile machinery operations.
Details
| Weight | 0.25 kg |
|---|---|
| Dimensions | 130 × 100 × 20 mm |
