High-Speed Frequency Input Module for Advantys STB Systems
The Schneider ASBDEP257C functions as a frequency input module within the Advantys STB distributed I/O platform. This module measures frequency and speed signals from encoders, flowmeters, and proximity sensors. Its high-speed counter design supports accurate monitoring of rotating machinery and process flows.
This frequency input module accepts up to 4 independent channels for versatile connectivity. A built-in scaling function converts raw frequency readings into engineering units for process applications. The device connects to the STB bus via the standard island bus interface.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASBDEP257C |
| Type | Frequency Input Module |
| Platform | Advantys STB |
| Number of Channels | 4 |
| Input Type | Pulse/frequency (TTL, NPN, PNP) |
| Frequency Range | 0 Hz to 1 MHz |
| Resolution | 16-bit |
| Scaling | Engineering unit conversion |
| Bus Interface | STB island bus |
| Isolation | 500 VAC (channel to bus) |
| Power Consumption | 150 mA (from bus supply) |
| Dimensions | 72 x 82 x 90 mm |
| Weight | 0.13 kg (approx.) |
| Operating Temp | 0 °C to 55 °C |
| Compliance | UL, CSA, CE, ATEX |
The ASBDEP257C offers four independent channels for simultaneous frequency measurement. Its 1 MHz range covers most industrial speed and flow sensing applications. The scaling function simplifies integration with DCS and SCADA systems.
This frequency input module supports TTL, NPN, and PNP input types for maximum flexibility. Its 500 VAC isolation protects the control bus from electrical interference. The module features hot-swap capability for minimal production disruption.
The ASBDEP257C integrates seamlessly with Advantys STB gateways and power supplies. Its robust design operates reliably across standard industrial temperature ranges. Therefore, this module provides a compact solution for frequency measurement in distributed I/O systems.
