16-Point Discrete Input for TSX Compact Automation Systems
The ASBDEO216 functions as a dedicated digital input module within Schneider Electric’s Modicon Compact platform. Engineers deploy this unit to capture discrete sensor signals across manufacturing and process control applications. Consequently, the module delivers reliable 24V DC input processing for legacy automation architectures.Schneider ASBDEO216 Modicon Compact Digital Input Module | 16-Point Specs
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | ASBDEO216 |
| Manufacturer | Schneider Electric (AEG) |
| Series | Modicon Compact (984) |
| Product Type | Discrete Input Module |
| Input Points | 16 |
| Input Voltage | 24V DC |
| Isolation Type | Non-Isolated |
| Compatible Systems | TSX Compact |
| Weight | 0.30 kg |
| Dimensions (L×W×H) | 14.2 × 11.2 × 4.0 cm |
| Country of Origin | Germany |
Input Architecture
The ASBDEO216 provides sixteen discrete input channels configured for 24V DC operation. Each point accepts standard industrial sensor signals for position, proximity, and limit detection. Therefore, the module suits applications requiring straightforward digital signal acquisition without complex isolation circuitry.
System Integration
The module integrates directly with Schneider Electric’s TSX Compact controller family. Engineers mount this unit within standard rack slots for straightforward installation and maintenance. Additionally, the compact footprint of 14.2 × 11.2 × 4.0 centimeters optimizes cabinet space utilization.Schneider ASBDEO216 digital input module for Modicon Compact/TSX systems. 16 points, 24V DC, 0.30kg. Non-isolated discrete input specs
Details
| Weight | 0.25 kg |
|---|---|
| Dimensions | 130 × 100 × 20 mm |
