The Schneider ASBDAU202 Analog Output Module delivers precise analog signal control for industrial automation, PLC systems, and continuous process applications. Its compact design, high signal accuracy, and dependable electrical performance help engineers achieve stable output control while improving overall system efficiency.
Product Overview
The ASBDAU202 converts digital control commands into accurate analog output signals for field instruments and industrial actuators. Furthermore, the module maintains consistent signal transmission during continuous production, allowing automation systems to respond quickly to changing process conditions. Its industrial-grade construction also supports reliable operation in demanding manufacturing environments with minimal maintenance requirements.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Schneider Electric |
| Model | ASBDAU202 |
| Product Category | Analog Output Module |
| Output Channels | 2 Analog Output Channels |
| Output Signal Type | 0–10 VDC, ±10 VDC, 4–20 mA |
| Resolution | 12-bit Digital-to-Analog Conversion |
| Output Accuracy | ±0.1% Full Scale |
| Communication Interface | Schneider PLC Backplane Interface |
| Power Supply | Internal Backplane Power |
| Mounting Method | Rack Installation |
| Dimensions | Approximately 150 × 115 × 40 mm |
| Weight | Approximately 0.35 kg |
| Internal Components | Precision DAC Circuit, Signal Conditioning Circuit, Industrial PCB |
| Energy Storage | Integrated Filter Capacitors for Stable Voltage Regulation |
| Isolation | Channel-to-System Electrical Isolation |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95%, Non-condensing |
Performance Advantages
The Schneider ASBDAU202 delivers accurate analog outputs while maintaining stable electrical performance throughout continuous industrial operation. In addition, the optimized signal conditioning circuitry minimizes electrical noise and improves output consistency across connected field devices. Engineers also appreciate the compact module because it simplifies cabinet installation and supports efficient automation system expansion.
Industrial Applications
The ASBDAU202 supports process automation, chemical production, water treatment, power generation, and manufacturing control systems requiring precise analog output control. Moreover, it connects seamlessly with variable frequency drives, control valves, actuators, and industrial transmitters, ensuring accurate signal delivery across every connected device. This capability improves production stability while helping operators maintain consistent process quality and equipment performance.
Why Choose Schneider ASBDAU202
Schneider Electric designs the ASBDAU202 to provide dependable analog output performance, flexible system compatibility, and long-term industrial reliability. Therefore, engineers can integrate the module into existing PLC platforms confidently while maintaining precise control across demanding automation applications. Its combination of high output accuracy, compact dimensions, and reliable electrical design makes it an excellent solution for modern industrial control systems.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
