High-Density Register Input Module for Advantys STB Systems
The Schneider ASB865001 functions as a register input module within the Advantys STB distributed I/O platform. This module reads 16-bit register data from field devices and transmits it to the bus master. Its compact design supports high-density analog and digital signal acquisition in automation networks.
This register input module provides 16 channels for versatile input configurations. A built-in status indicator displays active channel conditions for rapid diagnostics. The device connects to the STB bus via the standard island bus interface.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASB865001 |
| Type | Register Input Module |
| Platform | Advantys STB |
| Number of Channels | 16 |
| Input Type | 16-bit register data |
| Bus Interface | STB island bus |
| Isolation | 500 VAC (channel to bus) |
| Power Consumption | 120 mA (from bus supply) |
| Dimensions | 72 x 82 x 90 mm |
| Weight | 0.12 kg (approx.) |
| Operating Temp | 0 °C to 55 °C |
| Compliance | UL, CSA, CE, ATEX |
The ASB865001 offers 16 register input channels for flexible system integration. Its 500 VAC isolation protects the control bus from field-side electrical noise. The STB island bus connection ensures deterministic data exchange with the master controller.
This register input module features compact dimensions for DIN rail mounting. Its status indicator simplifies troubleshooting and maintenance procedures significantly. The module supports hot-swapping for minimal system downtime.
The ASB865001 integrates with Advantys STB gateways and power supplies seamlessly. Its robust design operates reliably across standard industrial temperature ranges. Therefore, this module delivers a cost-effective solution for register data acquisition.
Details
| Weight | 0.12 kg |
|---|---|
| Dimensions | 72 × 82 × 90 mm |
