16-Channel Digital Input Module for Advantys STB Systems
The Schneider ASB829016 functions as a digital input module within the Advantys STB distributed I/O platform. This module interfaces with field sensors, pushbuttons, and limit switches. Its 16-channel high-density design saves valuable cabinet space in automation panels.
Input Specifications and Signal Handling
This digital input module features 16 channels with a 24 VDC nominal voltage rating. Each channel provides optical isolation to protect the bus from field-side electrical noise. The module supports both sink and source wiring configurations. Furthermore, the built-in input filters suppress transient noise for reliable signal acquisition. Consequently, this module ensures stable readings from field devices.
Diagnostic and Communication Features
The ASB829016 connects to the STB bus via the standard island bus interface. Front-panel LEDs display individual channel status for quick troubleshooting. The module supports hot-swapping for minimal system downtime. Additionally, the diagnostic features simplify system maintenance procedures. For this reason, maintenance personnel can quickly identify and resolve wiring issues.
Physical Specifications and Environmental Ratings
This digital input module mounts on standard DIN rails. Its compact dimensions conserve valuable cabinet space. The module draws 80 mA from the bus supply for normal operation. Furthermore, it operates reliably from 0 °C to 55 °C ambient temperature. Consequently, this module provides a dependable input solution for distributed control applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASB829016 |
| Type | Digital Input Module |
| Platform | Advantys STB |
| Number of Channels | 16 |
| Nominal Voltage | 24 VDC |
| Input Type | Sink/source |
| Isolation | Optical (channel-to-bus) |
| Filter | Built-in noise suppression |
| Bus Interface | STB island bus |
| Mounting | DIN rail |
| Hot-Swap | Yes |
| Power Consumption | 80 mA |
| Dimensions | 72 x 82 x 90 mm |
| Weight | 0.11 kg (approx.) |
| Operating Temp | 0 °C to 55 °C |
| Compliance | UL, CSA, CE |
Details
| Weight | 0.11 kg |
|---|---|
| Dimensions | 72 × 82 × 90 mm |
