High-Density DC Output Module for Advantys STB Systems
The Schneider ASB828016 functions as a digital output module within the Advantys STB distributed I/O platform. This module drives 16 discrete output channels for controlling actuators, contactors, and indicator lights. Its high-density design saves valuable cabinet space in automation panels.
This output module features 16 sink/source channels with a 24 VDC nominal output. A built-in protection circuit guards against short-circuit and overload conditions. The module connects to the STB bus via the standard island bus interface.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ASB828016 |
| Type | Digital Output Module |
| Platform | Advantys STB |
| Number of Channels | 16 |
| Output Type | Sink/source (PNP/NPN) |
| Nominal Voltage | 24 VDC |
| Output Current | 0.5 A per channel |
| Protection | Short-circuit, overload |
| Bus Interface | STB island bus |
| Isolation | 500 VAC (channel to bus) |
| Power Consumption | 100 mA (from bus supply) |
| Dimensions | 72 x 82 x 90 mm |
| Weight | 0.11 kg (approx.) |
| Operating Temp | 0 °C to 55 °C |
| Compliance | UL, CSA, CE, ATEX |
The ASB828016 offers 16 sink/source output channels for maximum application flexibility. Its 0.5 A per channel rating handles most industrial control requirements. The short-circuit protection prevents damage from wiring faults or overload conditions.
This output module features compact dimensions for DIN rail mounting. The 500 VAC isolation protects the bus from field-side electrical noise. The module supports hot-swapping for minimal system downtime.
The ASB828016 integrates with Advantys STB gateways and power supplies seamlessly. Its robust design operates reliably across standard industrial temperature ranges. Therefore, this module provides a versatile solution for high-density output control.
Details
| Weight | 0.03 kg |
|---|---|
| Dimensions | 45 × 65 × 8 mm |
