This isolated output module delivers dependable digital control signals for Advantys I/O platforms. It drives actuators, contactors, and pilot lights in industrial automation applications. We designed the Schneider ASB810008 for the Advantys STB distributed I/O system. This module provides electrical isolation between the control side and field devices. It ensures safe and reliable output switching for your critical processes. Therefore, your automation system maintains robust performance and equipment protection.
Physical Configuration and Mounting Specifications
The Schneider ASB810008 features a compact modular design for DIN-rail mounting. Its dimensions measure 112.0 mm in height, 65.0 mm in width, and 85.0 mm in depth. The module weighs approximately 0.2 kilograms for straightforward installation procedures. This unit clips securely onto standard DIN-rail profiles. It connects to field wiring via removable screw-type terminal blocks. The module includes LED indicators for channel status and module health.
Output Specifications and Electrical Characteristics
This isolated output module offers 8 independent digital output channels. Each channel delivers a 24 VDC output signal to field devices. The Schneider ASB810008 provides 1500 VAC isolation between outputs and the system bus. It supports both sourcing and sinking output configurations for wiring flexibility. The module incorporates short-circuit and overload protection on each channel. It provides diagnostic feedback for open-load and over-temperature conditions. Consequently, this ensures reliable output performance in demanding industrial environments.
Detailed Technical Specifications and Interface Details
We present the module’s comprehensive technical parameters and operational capabilities below.
| Specification | Detail |
|---|---|
| Part Number | Schneider ASB810008 |
| Product Category | Isolated Output Module |
| Dimensions (H x W x D) | 112.0 mm x 65.0 mm x 85.0 mm |
| Module Weight | Approximately 0.2 kg (0.44 lbs) |
| Number of Output Channels | 8 isolated digital outputs |
| Output Signal Type | 24 VDC (sourcing or sinking configurable) |
| Output Voltage Range | 19.2 VDC to 28.8 VDC |
| Output Current | 0.5 A per channel maximum |
| Total Output Current | 4 A maximum (all channels) |
| Protection Features | Short-circuit, overload, over-temperature |
| Isolation Voltage | 1500 VAC (outputs to system bus) |
| Diagnostic Feedback | Open-load detection, over-temperature alarm |
| Output Filter | 0.5 ms typical |
| Switching Speed | 1 ms typical (ON to OFF) |
| Internal Power Dissipation | 2.5 W maximum |
| Field Wiring Connector | Removable screw terminal block |
| Wire Gauge Capacity | 0.5 to 2.5 mm² (AWG 20 to AWG 14) |
| Bus Interface | Advantys STB bus (ISOL bus) |
| Diagnostic Indicators | Green (power/run), red (fault), yellow (channel status) |
| Power Supply Voltage | 24 VDC (from field power supply) |
| Power Consumption | 0.5 W (logic) + output load |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Ingress Protection | IP20 |
| Compliance | CE, UL, CSA, RoHS |
