The ASB808016 discrete output module delivers reliable switching control for Modicon 800 Series automation platforms. Schneider Electric engineered this 16-point module to drive industrial loads with precision and durability. Engineers value its triac output structure and seamless rack-mount integration.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model | ASB808016 |
| Series | Modicon 800 / RMS-TSG-TZ-C |
| Category | Discrete Output Module |
| Output Points | 16 (2 groups of 8) |
| Output Type | Triac AC output |
| Voltage Range | 160–260 VAC |
| Frequency | 47–63 Hz |
| Max Current per Point | 2 A continuous |
| Max Surge Current | 50 A (one cycle) |
| Max Current per Group | 6 A |
| Max Current per Module | 12 A |
| Response Time | 8.3 ms (on/off) |
| Isolation | 500 Vrms |
| Leakage Current | 8 mA max @ 230 VAC |
| Terminal Connector | AS-8534-000 |
| Power Consumption | 76 mA @ +5V, 480 mA @ +4.3V |
| Dimensions | 35 x 20 x 10 cm |
| Weight | 0.3 kg |
| Operating Temperature | 0°C to 60°C |
| Protection Class | IP20 |
| Certifications | CE, UL, RoHS |
Key Features and Benefits
This output module provides sixteen independent 230VAC outputs organized into two groups of eight. Each point handles up to 2A continuous current and 50A surge for one cycle. Consequently, the module drives contactors, solenoid valves, and pilot lamps directly without intermediate relays.
The ASB808016 employs triac switches to control external loads reliably. The wide voltage range of 160–260VAC supports global industrial power standards. Additionally, the 8.3ms response time suits applications requiring precise timing and fast switching.
Applications and Compatibility
This module excels in manufacturing, packaging, and process control systems. It integrates seamlessly with Modicon 800 Series CPUs and backplanes. Furthermore, the compact rack-mount design simplifies installation and reduces control panel space requirements.
Details
| Weight | 0.3 kg |
|---|---|
| Dimensions | 350 × 200 × 100 mm |
