Precision Signal Acquisition for Process Monitoring
The Schneider ASB351001 analog input module provides eight isolated channels for acquiring 4-20 mA current signals from field sensors. This module accepts standard analog signals from pressure transmitters, temperature sensors, and flow meters in industrial processes. Each channel includes a 12-bit resolution analog-to-digital converter, ensuring accurate measurement with 0.1% precision. The module offers a 24V DC loop power supply for two-wire transmitters, simplifying field wiring. It also features programmable input filtering to reduce electrical noise and signal fluctuations. Moreover, the module provides per-channel diagnostics for detecting open-circuit or short-circuit conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Input Module |
| Product Line | Modicon Series |
| Input Channels | 8 isolated analog inputs |
| Input Signal | 4-20 mA (standard) |
| Resolution | 12 bits |
| Accuracy | ±0.1% of full scale |
| Loop Supply | 24V DC (per channel) |
| Input Impedance | 250 Ω |
| Conversion Time | 10 ms per channel |
| Filtering | Programmable digital filter |
| Diagnostics | Open-circuit and short-circuit detection |
| Power Supply | 24V DC ±20% |
| Power Consumption | 120 mA typical |
| Electrical Isolation | 1500V between channels and bus |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions (W x H x D) | 120 x 80 x 50 mm |
| Weight | 0.25 kg |
| Mounting | DIN-rail |
| Certifications | CE, UL, RoHS |
| Product Origin | France |
Application and System Integration
Engineers commonly deploy the Schneider ASB351001 in HVAC systems, water treatment plants, and chemical processing lines. This module integrates seamlessly with Modicon M580 and M340 PLCs through the standard backplane. It provides real-time analog data for critical process control loops. The module supports multiple input ranges and includes surge protection for robust performance. Consequently, plant operators achieve better process visibility and tighter control over production variables.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
