The Schneider AS8535000 connector provides a robust interface for distributed I/O systems in demanding automation environments. This high-density module supports up to 128 I/O points per node, significantly reducing cabinet space requirements. Its compact design measures 85 mm in width, 95 mm in height, and 62 mm in depth, making it ideal for space-constrained control panels.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AS8535000 |
| I/O Density | High-density (up to 128 points per node) |
| Dimensions (W×H×D) | 85 × 95 × 62 mm |
| Weight | 0.35 kg |
| Connector Type | Spring-clamp terminal blocks |
| Wire Gauge Range | 0.2 – 2.5 mm² (AWG 24–12) |
| Operating Temperature | –25°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Relative Humidity | 5% – 95% (non-condensing) |
| Vibration Resistance | 5 g, 10–500 Hz |
| Shock Resistance | 30 g, 11 ms |
| Protection Rating | IP20 |
Connector Interface and Wiring Flexibility
Each AS8535000 unit features 40 spring-clamp terminal points for secure and maintenance-free wiring. The connector accepts both solid and stranded conductors without requiring special tools. You can insert wires ranging from 0.2 to 2.5 mm², accommodating most field cabling standards. The terminal design ensures reliable signal transmission even under continuous vibration up to 5 g.
Performance and Environmental Durability
The module operates reliably across a wide temperature range from –25°C to +70°C. Its robust housing withstands shock loads up to 30 g and vibration frequencies from 10 to 500 Hz. Such resilience makes the Schneider AS8535000 suitable for harsh industrial settings, including automotive assembly lines and heavy machinery control stations.
Integration with Schneider Electric Ecosystems
This connector integrates seamlessly with Modicon M580 and M340 programmable automation controllers. It supports both Profibus DP and Modbus TCP communication protocols, ensuring broad compatibility with existing plant networks. The module consumes only 1.2 W of power, contributing to overall energy efficiency in control cabinets.
Installation and Maintenance Advantages
The spring-clamp technology eliminates the need for screw tightening, reducing installation time by approximately 30%. You can mount the connector vertically or horizontally on standard DIN rails (35 mm). Its clear labeling scheme simplifies field troubleshooting, allowing technicians to identify wiring points quickly. The housing material meets UL 94 V-0 flammability standards, enhancing fire safety in critical applications.
Ordering and Packaging Information
Each package contains one AS8535000 connector, one user manual, and a set of coding keys for preventing misinsertion. The unit weighs 0.35 kg and ships in anti-static packaging to prevent electrostatic discharge damage during transit.
Details
| Weight | 0.25 kg |
|---|---|
| Dimensions | 130 × 100 × 20 mm |
