Technical Overview
The Schneider Electric AS-BDAO-216 is a 16-channel discrete output module designed for the Modicon TSX Compact and Quantum PLC platforms . This module converts digital control signals from the processor into 24 VDC outputs for driving actuators, relays, contactors, and indicator lamps . It organizes its outputs as a single group with a common power connection, thereby simplifying field wiring . Users can wire the module in either sink or source configurations to match various load requirements. The module includes LED indicators on the front panel that display the ON-OFF status of each channel, simplifying field troubleshooting .
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model Number | AS-BDAO-216 |
| Product Type | Discrete Output Module |
| System Compatibility | Modicon TSX Compact, Quantum |
| Output Channels | 16 |
| Output Type | Transistor (sink/source configurable) |
| Output Voltage | 24 VDC nominal |
| Output Current per Point | 0.5 A |
| Load Voltage Range | 10-60 VDC |
| Power Consumption | 8 W typical |
| Isolation | Non-isolated |
| Response Time | Microsecond range |
| Dimensions | 14.2 x 11.2 x 4.0 cm |
| Weight | 0.3 kg |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
| Mounting | DIN rail or rack mount |
| Certifications | CE, UL, CSA |
| Country of Origin | USA |
Key Features
High Channel Density – The 16-channel design provides extensive output capacity in a single module, saving valuable rack space. It simplifies system architecture and reduces overall hardware costs.
Flexible Output Configuration – Users can configure each channel for sink or source wiring, accommodating various field devices. This versatility eliminates the need for external interface relays in many applications.
High-Speed Switching – The microsecond response time supports high-speed control tasks for demanding automation workflows . This speed makes the module suitable for applications requiring rapid output updates.
Industrial-Grade Construction – The module operates reliably from -20°C to +60°C and features IP20 protection against solid objects . Its robust design ensures durability in demanding factory environments.
Visual Status Indication – LED indicators on the front panel display the ON-OFF status of each output channel . This feature simplifies troubleshooting and reduces maintenance time.
Applications
The Schneider Electric AS-BDAO-216 suits discrete manufacturing, process control, and material handling systems. It provides reliable output control for solenoid valves, contactors, motor starters, and indicator lamps in automotive, food and beverage, chemical, and packaging industries .
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
