Versatile Input/Output Interface for Field Devices
The Schneider 920093602 digital I/O module provides a flexible interface for connecting sensors and actuators to Modicon PLC systems. This module integrates 16 digital inputs and 16 digital outputs in a single compact housing. The inputs accept signals from pushbuttons, limit switches, or proximity sensors with a 24V DC nominal voltage. The outputs can drive solenoids, contactors, or indicator lamps with a 2A current rating per channel. The module also features individual LED status indicators for quick diagnostics. Furthermore, it includes electrical isolation between the field side and the system bus.
Detailed Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Digital Input/Output Module |
| Product Line | Modicon Series |
| Input Channels | 16 digital inputs |
| Input Voltage | 24V DC nominal (range: 0-30V DC) |
| Input Current | 7 mA per channel |
| Input Filtering | Configurable 0.1 ms to 12 ms |
| Output Channels | 16 digital outputs |
| Output Type | Transistor (sourcing) |
| Output Current | 2A per channel (8A total) |
| Output Protection | Short-circuit and overcurrent protection |
| Switching Frequency | Up to 100 Hz |
| Supply Voltage | 24V DC ±20% |
| Power Consumption | 150 mA typical |
| Electrical Isolation | 500V between field and bus |
| LED Indicators | Per-channel status for inputs and outputs |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 105 x 85 x 45 mm |
| Weight | Approximately 0.3 kg |
| Mounting | DIN-rail or panel |
| Certifications | CE, UL, CSA |
| Product Origin | France |
Advanced Feature Set for Robust Control
This module employs a configurable input filter to suppress contact bounce and electrical noise, ensuring clean signal acquisition. Each output channel includes integrated short-circuit and overcurrent protection, safeguarding the module and connected loads from damage. The transparent housing provides clear visibility of all LED status indicators, simplifying routine maintenance and system verification. Moreover, the module supports hot-swapping for quick replacement without interrupting the entire system’s operation.
Seamless System Integration
Engineers commonly deploy the Schneider 920093602 in conveyor systems, packaging lines, and material handling applications. This module integrates seamlessly with Modicon M340 and M580 PLCs through a standard backplane bus. It provides real-time status feedback for critical control loops in automated machinery. Consequently, plant operators gain improved diagnostic capabilities and faster fault detection, leading to higher overall equipment effectiveness (OEE).
