The Schneider 553VIC10101 industrial monitor delivers reliable visual feedback for factory automation and process control applications. This 10.4-inch TFT LCD screen provides operators with clear, high-contrast display of critical process data. The Schneider 553VIC10101 features a resistive touchscreen interface for intuitive operator interaction with control systems. Its rugged construction includes a robust metal housing that withstands vibration and mechanical shock. The monitor supports multiple mounting options, including panel, rack, and VESA configurations. This versatility allows the 553VIC10101 to integrate seamlessly into diverse control console designs.
Display Characteristics and Optical Performance
The Schneider 553VIC10101 offers a resolution of 800 x 600 pixels for sharp text and graphics rendering. This SVGA display produces 262,000 colors for clear visualization of process variables and alarms. The monitor delivers a brightness rating of 400 cd/m² for excellent readability in well-lit factory conditions. An anti-glare coating minimizes reflections from overhead lighting and windows. The 553VIC10101 provides a viewing angle of 140 degrees horizontal and 120 degrees vertical. This wide viewing angle allows multiple operators to view the screen from different positions. The backlight uses CCFL technology with a typical life of 50,000 hours for long-term reliability.
The Schneider 553VIC10101 measures 11.5 inches in height, 10.5 inches in width, and 2.8 inches in depth. This industrial monitor weighs approximately 6.5 pounds, requiring sturdy mounting support. The front panel meets NEMA 4X and IP65 standards for water and dust resistance. This protection makes the 553VIC10101 suitable for washdown areas and outdoor enclosures.
Connectivity, Interfaces, and Compatibility
The Schneider 553VIC10101 accepts analog VGA and digital DVI inputs for compatibility with most industrial computers. This monitor also provides a composite video input for connecting to legacy CCTV equipment. The 553VIC10101 includes a built-in USB port for touchscreen connection to a host PC. A serial RS-232 interface provides an alternative touch communication path for older systems. The monitor operates on 24 VDC power input, drawing 25 watts under typical conditions.
Full Technical Specifications Table
| Parameter | Specification |
|---|---|
| Part Number | 553VIC10101 |
| Screen Size | 10.4 inches diagonal |
| Resolution | 800 x 600 (SVGA) |
| Display Colors | 262,000 |
| Brightness | 400 cd/m² |
| Contrast Ratio | 500:1 |
| Viewing Angle (H/V) | 140° / 120° |
| Backlight Type | CCFL (50,000 hrs) |
| Touchscreen | Resistive (analog) |
| Video Inputs | VGA, DVI, Composite |
| Touch Interfaces | USB, RS-232 |
| Front Panel Rating | NEMA 4X / IP65 |
| Mounting Options | Panel, rack, VESA |
| Dimensions (H x W x D) | 11.5 x 10.5 x 2.8 inches |
| Weight | 6.5 lbs |
| Input Power | 24 VDC, 25W |
| Operating Temperature | 0 to 55°C |
Application Scenarios and Installation Advantages
The Schneider 553VIC10101 serves as a reliable operator interface for machine control and process monitoring. This monitor pairs effectively with Schneider Electric PLCs and industrial computers. The 553VIC10101 also works with third-party controllers through its standard video connections. Its rugged design reduces downtime from display failures in demanding industrial settings. The Schneider 553VIC10101 delivers clear visual information to operators in manufacturing and processing plants.
Details
| Weight | 0.55 kg |
|---|---|
| Dimensions | 140 × 49 × 145 mm |
