Product Overview

This Ethernet cabling system provides reliable network connectivity for Modicon automation equipment. It connects programmable controllers, operator workstations, and remote I/O stations. The 499NOH00510 serves as a complete cabling solution for industrial communication networks. Its assembly includes pre-terminated cables and connectors for simplified installation. This system eliminates the need for on-site cable preparation and termination tasks.

Technical Specifications

The 499NOH00510 consists of a 5-meter shielded Ethernet cable with RJ45 connectors at both ends. The cable features 24 AWG stranded copper conductors for maximum installation flexibility. This assembly weighs approximately 0.25 kg, including the cable and connector housings. It supports data transfer rates of 10 Mbps and 100 Mbps for standard Ethernet networks. The cable meets Category 5e performance specifications for reliable signal integrity. Its shielding provides excellent protection against electromagnetic interference in industrial environments. The cable’s outer jacket meets UL and CSA flame resistance standards. This system also includes two ferrite beads for additional noise suppression. The connectors feature robust metal housings with strain-relief boots for extended durability. Each cable undergoes factory testing to verify full performance compliance.

Construction and Installation Features

This cabling system uses high-quality materials for long service life in harsh conditions. The connectors latch securely to prevent accidental disconnection during equipment operation. The 499NOH00510 includes color-coded conductors for simplified identification and troubleshooting. Its flexible design allows routing through cable ducts and tight spaces with ease. The integrated strain relief protects the conductors from damage during installation.

Physical and Electrical Parameters

System Integration and Application

Connect the 499NOH00510 between Ethernet devices using standard RJ45 interfaces. This system works with Modicon M340, M580, and Quantum controllers directly. It also supports connections to industrial Ethernet switches and programming terminals. The cable’s length suits typical cabinet-to-cabinet or device-to-switch installations. Its shielded design provides reliable communication in high-noise environments.

Typical Applications

This cabling system serves factory automation networks and process control installations. It connects PLCs to HMIs, SCADA servers, and engineering workstations. The 499NOH00510 also links remote I/O drops to central controllers. Its factory-terminated construction ensures consistent network performance.
