4-Channel Analog Output Module for Modicon Momentum Systems
The Schneider 170XTS00501 functions as an analog output module within the Modicon Momentum automation platform. This module converts digital values from the controller into proportional analog signals for field actuators. Its 4-channel design supports precise control of valves, drives, and other modulating devices.
This analog output module provides 0 to 10 VDC and 4 to 20 mA outputs with 12-bit resolution. A built-in diagnostic feature monitors output status for fault detection and troubleshooting. The module connects to the Momentum bus via the standard I/O interface.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 170XTS00501 |
| Type | Analog Output Module |
| Platform | Modicon Momentum |
| Number of Channels | 4 |
| Output Ranges | 0 to 10 VDC, 4 to 20 mA |
| Resolution | 12-bit |
| Load Impedance | 500 Ω (current), 2 kΩ (voltage) |
| Accuracy | ±0.25% of full scale |
| Diagnostics | Output fault detection |
| Bus Interface | Momentum I/O bus |
| Isolation | 1500 VAC (channel to bus) |
| Power Consumption | 80 mA (from bus supply) |
| Dimensions | 108 x 86 x 50 mm |
| Weight | 0.18 kg (approx.) |
| Operating Temp | 0 °C to 60 °C |
| Compliance | UL, CSA, CE |
The 170XTS00501 offers four channels for flexible analog output control. Its 12-bit resolution ensures precise signal generation for process applications. The diagnostic feature provides visual fault indication for rapid troubleshooting.
This analog output module produces both voltage and current signals for versatile actuator compatibility. Its 1500 VAC isolation protects the control bus from field-side electrical noise. The module mounts on a standard DIN rail for straightforward installation.
The 170XTS00501 integrates with Momentum processors and I/O modules seamlessly. Its robust design operates reliably across industrial temperature ranges. Therefore, this module delivers precise analog control for compact automation systems.
Details
| Weight | 0.18 kg |
|---|---|
| Dimensions | 108 × 86 × 50 mm |
