Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Communication Module (Ethernet/IP) |
| Compatibility | Modicon Quantum PLC Series |
| Network Interface | 2 x Ethernet ports (RJ45, 10/100 Mbps) |
| Protocol Support | EtherNet/IP, Modbus TCP/IP, SNMP |
| Number of Connections | 64 CIP connections maximum |
| Data Exchange | 5000 bytes input / 5000 bytes output |
| IP Addressing | DHCP, BootP, or static assignment |
| Dimensions (H x W x D) | 260 mm x 80 mm x 145 mm |
| Weight | 1.0 kg |
| Power Consumption | 5.0 W typical |
| Current Draw (5 VDC) | 800 mA |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % (non-condensing) |
| Protection Class | IP20 |
| Certifications | CE, UL, CSA, ODVA compliant |
Network Connectivity and Protocols
The 140NOL91110C communication module provides robust Ethernet/IP connectivity for Modicon Quantum PLC systems. This unit features two independent RJ45 Ethernet ports, each supporting 10/100 Mbps auto-negotiation for flexible network integration. It simultaneously handles Modbus TCP/IP and EtherNet/IP protocols, allowing seamless communication with various industrial devices such as drives, HMIs, and remote I/O stations. Furthermore, the module supports 64 concurrent CIP connections, which enables large-scale data exchange across distributed control architectures.
Data Exchange Capacity
Each communication cycle on the 140NOL91110C processes up to 5000 bytes of input data and 5000 bytes of output data, ensuring sufficient bandwidth for demanding applications. This substantial capacity accommodates complex data structures, including arrays, strings, and user-defined data types. Consequently, system integrators can transfer large datasets without segmentation or performance degradation.
Physical Configuration and Installation
Weighing 1.0 kg and matching the standard Quantum form factor of 260 mm x 80 mm x 145 mm, this module installs directly into any available rack slot. The unit draws 800 mA from the 5 VDC backplane supply, consuming 5.0 W of power during normal operation. Users can assign IP addresses through DHCP, BootP, or manual static configuration, providing deployment flexibility for various network environments.
Diagnostic and Monitoring Features
The 140NOL91110C includes comprehensive diagnostic LEDs that display link status, activity, and module health at a glance. Network administrators can access detailed performance metrics via SNMP or the embedded web server, facilitating proactive maintenance. Additionally, the module logs communication errors and connection events, simplifying troubleshooting procedures.
Details
| Weight | 1.0 kg |
|---|---|
| Dimensions | 260 × 80 × 145 mm |
