High-Performance Network Connectivity for Modicon Quantum
The 140NOE77101C Ethernet communication module provides robust network connectivity for Modicon Quantum automation platforms. This module supports dual 10/100BASE-TX Ethernet ports with an embedded 4-port switch for flexible network topologies. It delivers 10/100 Mbps auto-sensing speeds, enabling fast data exchange with supervisory systems and HMIs. This module also operates with efficient power consumption, utilizing Power over Ethernet (PoE) on its expansion port.
Protocol Support and Data Exchange Capabilities
The 140NOE77101C module supports extensive industrial protocols for seamless system integration. It handles Modbus TCP, EtherNet/IP, SNMP, and HTTP protocols for versatile connectivity. This module also enables I/O scanning, global data sharing, and messaging services across the network. Additionally, the 140NOE77101C can function as a web server for remote monitoring. It supports a maximum of 64 simultaneous connections to facilitate data exchange.
Memory and Data Processing Specifications
The 140NOE77101C module includes 16 MB of onboard RAM for robust data handling. It also features 8 MB of flash memory for firmware storage and configuration retention. This module can process up to 1024 words in its internal data buffers.
Physical Dimensions and Environmental Ratings
This single-width module weighs approximately 1.25 kg and fits standard Quantum racks. It operates reliably from 0°C to 60°C and stores safely from -40°C to +85°C. The module also withstands 10% to 95% relative humidity without condensation, ensuring stable performance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon Quantum |
| Model | 140NOE77101C |
| Module Type | Ethernet TCP/IP Communication Module |
| Number of Ports | 2 (10/100BASE-TX), 1 expansion |
| Data Rate | 10/100 Mbps auto-sensing |
| Protocols Supported | Modbus TCP, EtherNet/IP, SNMP, HTTP, TCP/IP, UDP, BOOTP, DHCP |
| Transmission Distance | 100 m |
| Transmission Speed | 10/100 Mbps (auto-negotiation) |
| Communication Services | Messaging, Global Data, I/O Scanning, Web Server |
| Number of Connections | 64 |
| I/O Scanning Inputs | 4000 words |
| I/O Scanning Outputs | 4000 words |
| Program Memory | 16 MB RAM, 8 MB Flash |
| Power Supply | 24 V DC |
| Current Consumption | 400 mA at 5 V DC |
| Standards | IEEE 802.3, EN 61131-2 |
| Weight | Approx. 1.25 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 10 to 95% (non-condensing) |
| Protection | IP20 |
| Certifications | CE, UL 508, CSA C22.2 No 142, DNV, ABS, BV, GL, LR, RINA, RMRS |
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
