The 140NOE31100C functions as a network option module within Schneider Modicon Quantum platforms. This unit connects controllers to Ethernet networks for plant-wide data exchange. Engineers select it for distributed architectures requiring dependable industrial communication.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Network Option Module |
| Compatibility | Schneider Modicon Quantum PLC Systems |
| Module Width | Single-width Quantum housing |
| Weight | Approximately 0.6 kg |
| Interface Type | Ethernet network connection port |
| Network Protocol | Industrial Ethernet communication support |
| Data Transfer Rate | Standard Ethernet transmission speeds |
| Connector Type | Integrated RJ45 network connector |
| Isolation | Network-to-system signal isolation |
| Power Supply | Via Quantum backplane power rail |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Mounting Style | Standard Quantum rack mounting |
Functional Overview
This module links Quantum controllers to Ethernet networks for plant-wide data exchange. Consequently, it enables supervisory systems to collect real-time production data. The 140NOE31100C supports industrial Ethernet protocols through an integrated RJ45 port. Therefore, system integrators build networked control architectures without extra gateway hardware.
Integration and Compatibility
The 140NOE31100C fits directly into standard Modicon Quantum racks. Additionally, it exchanges data through the backplane bus and network port. This arrangement reduces cabling effort and simplifies network commissioning. Furthermore, the module maintains stable transmission across extended cable runs.
Typical Applications
Manufacturers deploy this network module in SCADA integration, remote monitoring, and plant data systems. Moreover, it suits applications requiring dependable Ethernet communication. The 140NOE31100C excels where networked control performance matters most.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
