The Schneider 140DVO85300C provides 32 discrete output channels for PLC systems. This output module weighs only 0.4 kilograms for lightweight rack mounting. Its dimensions measure 140 mm in height and 135 mm in depth. The width stands at 32 mm for standard Quantum rack installation.
Technical Specifications of 140DVO85300C
The Schneider 140DVO85300C delivers transistor outputs with 0.5 amps per channel. Each output handles up to 24 V DC loads directly. The module operates on a 5 V DC supply from the backplane. It draws only 300 milliamps during full load operation. Therefore, this output module offers excellent power efficiency for its channel count.
Below is a complete breakdown of key parameters:
| Parameter | Value |
|---|---|
| Product Model | 140DVO85300C |
| Manufacturer | Schneider Electric |
| Product Type | Discrete Output Module |
| Number of Outputs | 32 |
| Output Type | Transistor (sourcing) |
| Output Voltage | 24 V DC |
| Output Current | 0.5 A per channel |
| Backplane Supply | 5 V DC |
| Current Draw | 300 mA |
| Weight | 0.4 kg |
| Dimensions (H x W x D) | 140 x 32 x 135 mm |
| Connector Type | 40-pin female header |
| Operating Temperature | 0°C to +60°C |
Output Features and Protection
The Schneider 140DVO85300C includes built-in short-circuit protection per channel. Each output also features an individual LED status indicator. The module stores no internal energy or backup battery. Consequently, you need external power supplies for load circuits. This design eliminates battery replacement maintenance tasks entirely.
Installation and System Integration
You can install this module into any Quantum series rack slot. It automatically configures its I/O mapping during power-up. The Schneider 140DVO85300C works seamlessly with Unity Pro software. For similar industrial output solutions, see the RMS-TSG-TZ-C static trip unit. That unit provides reliable protection for power distribution systems. However, the 140DVO85300C focuses specifically on discrete output control tasks.
Performance and Reliability Features
This output module supports a maximum switching frequency of 500 Hz. It tolerates output short circuits without permanent damage. The Schneider 140DVO85300C includes optical isolation between backplane and outputs. Moreover, its robust design withstands surge voltages up to 1 kV. These features make it ideal for factory automation and machine control.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
