Remote I/O Network Interface for Modicon Quantum
The 140CRP93200C remote I/O adapter module serves as the head-end interface for Modicon Quantum distributed control systems. This module connects Quantum controllers to remote I/O drops over a fiber optic network infrastructure. It uses a dual-ring topology for reliable communication, ensuring no single point of failure . This module handles high-speed data exchange between the processor and distributed field devices.
Communication Performance and Network Specifications
The 140CRP93200C supports a 10/100 Mbps Ethernet link for seamless data transmission. This module provides network aggregation and enables Modbus TCP communication between remote substations. It achieves a maximum distance of 15 km between the main and remote drops, making it ideal for large-scale facilities . Additionally, this adapter module supports up to 31 remote drops per network, offering excellent scalability . The 140CRP93200C also serves as a gateway between Ethernet and fiber optic networks.
Physical Characteristics and Environmental Ratings
This single-width module weighs approximately 1.3 kg and fits standard Quantum racks. It operates reliably from 0°C to 60°C and stores safely from -40°C to +85°C. The module also withstands 10% to 95% relative humidity without condensation . It carries CE marking and holds UL 508 certification for safety compliance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Line | Modicon Quantum |
| Model | 140CRP93200C |
| Module Type | RIO Head-End Adapter Module |
| Communication Ports | 1 fiber optic (main), 1 RJ45 Ethernet |
| Data Rate | 10/100 Mbps (auto-negotiation) |
| Topology | Dual-Ring |
| Transmission Medium | Fiber optic (redundant) |
| Maximum Distance | 15 km |
| Maximum Remote Drops | 31 |
| Protocols | Modbus TCP, TCP/IP |
| Services | Global Data, I/O Scanning, Peer Cop |
| Power Supply | 24 V DC |
| Current Consumption | 400 mA at 5 V DC |
| Power Dissipation | ≤ 5 W |
| Weight | 1.3 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 10 to 95% (non-condensing) |
| Protection | IP20 |
| Certifications | CE, UL 508, CSA C22.2 No 142 |
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
