Core Technical Specifications
This power supply module delivers reliable DC power to your control system components. We engineered the 140CPS11100C to provide stable voltage under varying load conditions.
| Parameter | Specification |
|---|---|
| Product Type | Power Supply Module |
| Dimensions | 130 mm x 100 mm x 85 mm (W x H x D) |
| Weight | 0.60 kg |
| Input Voltage | 100–240 V AC nominal (range: 85–264 V AC) |
| Input Frequency | 47–63 Hz |
| Output Voltage | 24 V DC nominal |
| Output Current | 10 A continuous |
| Output Power | 240 W maximum |
| Hold-Up Time | 10 ms at full load |
| Inrush Current | 30 A peak (cold start) |
| Efficiency | 85% typical at nominal load |
| Protection Features | Overvoltage, overcurrent, and short-circuit protection |
| LED Indicators | Green “PWR” for output status, red “FLT” for fault |
| Mounting | Rack-mounted via backplane connector |
| Operating Temp. | 0 °C to 60 °C |
| Certifications | CE, UL 508, CSA, and ATEX Zone 2 |
Wide-Range Input Compatibility
The 140CPS11100C accepts universal AC input from 85 to 264 V AC and 47 to 63 Hz. This wide range accommodates power mains in all global regions without manual voltage selection. You can install this module confidently in facilities with unstable or fluctuating supply voltage. The built-in filtering suppresses line noise and transients, ensuring clean output for sensitive electronics.
Robust Output Performance
This power supply delivers 24 V DC at 10 A continuous, providing sufficient capacity for most Modicon I/O racks. The 240 W maximum output powers CPUs, communication modules, and field devices reliably. The module maintains output regulation within ±5% across all load and line conditions. Furthermore, the 10 ms hold-up time keeps the system running through brief power interruptions.
Comprehensive Protection Features
The 140CPS11100C integrates overvoltage, overcurrent, and short-circuit protection for complete system safety. These protective circuits automatically limit output during fault conditions, preventing damage to connected modules. The module recovers automatically after removing the fault, with no need for manual fuse replacement. Additionally, front-panel LED indicators provide instant visual status feedback for power and fault conditions.
Efficient Thermal Management
This power supply operates at 85% typical efficiency, reducing energy consumption and heat dissipation. The low heat output allows mounting adjacent to other modules without overheating concerns. The natural convection cooling design eliminates the need for internal fans. Consequently, the 140CPS11100C operates silently and requires no periodic filter cleaning or fan maintenance.
Rugged Design for Industrial Applications
The 140CPS11100C holds ATEX Zone 2 certification for installation in potentially explosive environments. It operates reliably across a wide 0 °C to 60 °C temperature range. The compact 130 x 100 x 85 mm form factor fits standard Quantum racks. Weighing just 0.60 kg, this module adds minimal mechanical strain to the chassis assembly.
Details
| Weight | 0.60 kg |
|---|---|
| Dimensions | 130 × 100 × 85 mm |
