The 140ACO13000C analog output module delivers precise signal control for Modicon Quantum systems. This Schneider unit converts digital data into reliable analog outputs across industrial processes. Engineers choose it for accurate current and voltage regulation tasks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Output Module |
| Compatibility | Modicon Quantum PLC Platforms |
| Output Channels | 8 Analog Outputs |
| Output Signals | 4–20 mA, 0–20 mA, 0–10 V |
| Resolution | 12-Bit |
| Interface | Quantum Backplane Bus |
| Dimensions | 250 mm x 40 mm x 180 mm |
| Weight | Approximately 0.85 kg |
| Component Count | 38 Active Electronic Components |
| Energy Storage | 3.0 V Lithium Backup Battery |
| Power Consumption | 5 VDC at 1.5 A |
| Operating Temperature | 0°C to 60°C |
| Relative Humidity | 5% to 95%, Non-Condensing |
Output Performance and Accuracy
Each channel delivers 12-bit resolution for smooth, granular signal control. Therefore, the module maintains ±0.1% accuracy across its full output range. Furthermore, users configure current or voltage modes through software settings. Consequently, one unit adapts to multiple field device requirements.
Interface and Integration
A backplane connector links the 140ACO13000C directly to the Quantum rack. As a result, data exchanges happen quickly without external wiring. Additionally, front-panel indicators show channel status and fault conditions.
Power and Backup
The module draws 5 VDC at 1.5 A from the system supply. Moreover, a 3.0 V lithium battery protects calibration data during outages. Consequently, technicians avoid recalibration after brief power interruptions.
Installation Notes
Operators insert the unit into a standard Quantum slot for quick setup. The module occupies one single-width position, which saves valuable chassis space. However, users should confirm firmware compatibility before commissioning.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
