Technical Overview
The Schneider 110CPU41101 serves as a high-performance CPU processor for the Modicon M580 ePAC platform. This module operates a 1.2 GHz dual-core processor that delivers exceptional scanning speed for complex automation applications. Its substantial 4 GB of RAM and 8 GB of flash memory accommodate demanding programs, extensive data logs, and multiple communication services, respectively. Consequently, the 110CPU41101 excels in process industries, water treatment facilities, and large-scale material handling systems.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | CPU Processor / ePAC Controller |
| Processor | 1.2 GHz dual-core |
| RAM Memory | 4 GB |
| Flash Memory | 8 GB |
| Embedded Ethernet Ports | 2 × Gigabit (dual-port switch) |
| USB Ports | 1 × USB 2.0 (programming) |
| Serial Port | 1 × RS-232 (service) |
| Max I/O Points | Up to 512 modules / 2048 I/O |
| Communication Protocols | EtherNet/IP, Modbus TCP, OPC UA |
| Power Supply | 24 VDC |
| Current Draw | 1.2 A |
| Battery Backup | Internal lithium (10 years) |
| Dimensions (H x W x D) | 105 x 140 x 120 mm |
| Weight | 0.9 kg |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 |
| Safety Certification | SIL 2 (functional safety ready) |
Processing Power and Memory Capacity
The Schneider 110CPU41101 handles complex control algorithms, multiple PID loops, and high-speed data acquisition simultaneously with its dual-core architecture. Its 4 GB RAM supports extensive array processing and large data tables, while the 8 GB flash stores firmware backups and application versions securely.
Advanced Connectivity and Network Architecture
Dual Gigabit Ethernet ports with embedded switch functionality enable daisy-chain and star network topologies without external switches. The 110CPU41101 supports EtherNet/IP for I/O control, Modbus TCP for device communication, and OPC UA for IT integration. This unified connectivity simplifies system architecture and reduces hardware costs significantly.
Reliability and Diagnostics
Built-in battery backup preserves program data and real-time clock settings for up to a decade. LED indicators provide immediate status feedback for power, run, fault, and Ethernet link activity. Furthermore, the module integrates web-based diagnostics, allowing operators to monitor system performance remotely through standard web browsers.
Details
| Weight | 0.9 kg |
|---|---|
| Dimensions | 105 × 140 × 120 mm |
