High-Performance HMI for Advanced Applications

This QuickPanel HMI provides a versatile and powerful interface for complex automation tasks. The QPK-3D200-S2P features a large, high-resolution display for superior data visualization. It supports extensive communication options, ensuring seamless connectivity with various devices. The panel’s robust design guarantees reliable performance in challenging industrial conditions. Consequently, the QPK-3D200-S2P significantly improves operator effectiveness and system oversight.

Technical Specifications and Physical Attributes

The features a 12.1-inch TFT display with a resolution of 800 x 600 pixels. It offers 64 MB of RAM and 64 MB of flash memory for storing applications. The panel includes Ethernet, RS-232, and RS-485 ports for comprehensive connectivity. It measures approximately 325 mm in width, 240 mm in height, and 55 mm in depth. The unit weighs about 2.8 kg. Furthermore, the operates within a temperature range of 0 °C to 50 °C. Its IP65 rating protects against dust and water ingress.

Integration and Application Guidance

This HMI serves as a central control point for sophisticated machine and process automation. First, mount the QPK-3D200-S2P securely into the designated panel cutout. Then, connect the Ethernet or serial cables to the PLC or network switches. For power, wire the 24 V DC supply to the appropriate terminals. Finally, download the application using the QuickDesigner software. The QPK-3D200-S2P excels in automotive, pharmaceutical, and food and beverage industries.
