Intuitive Operator Interface for Industrial Control

This HMI touchpanel provides a user-friendly interface for monitoring and controlling automation systems. The QPJ-2D100-S2P offers a high-resolution display for clear visualization of process data. It supports multiple communication protocols for seamless integration with GE and third-party devices. The touchpanel’s rugged construction withstands demanding industrial environments effectively. Consequently, the QPJ-2D100-S2P enhances operator efficiency and system productivity.

Technical Specifications and Physical Attributes

The features a 10-inch TFT color display with a resolution of 800 x 480 pixels. It includes 64 MB of RAM and 64 MB of flash memory for application storage. The panel offers Ethernet, RS-232, and RS-485 ports for versatile connectivity. It measures approximately 278 mm in width, 194 mm in height, and 42 mm in depth. The unit weighs about 1.5 kg. Furthermore, the operates within a temperature range of 0 °C to 50 °C. Its IP65 rating provides protection against dust and water ingress.

Integration and Application Guidance

This touchpanel serves as a central HMI for machine and process control applications. First, mount the QPJ-2D100-S2P securely into the designated panel cutout using the provided clips. Then, connect the Ethernet or serial cables to the PLC or network. For power, wire the 24 V DC supply to the appropriate terminals. Finally, download the application using the QuickDesigner software. The QPJ-2D100-S2P excels in packaging, material handling, and factory automation.
