The GE IS200WEORG1A IS200WEORG1ACD manages wind turbine operations within a Mark VIe control system. This board handles pitch control signals and generator monitoring functions. It weighs approximately 0.88 kg and occupies a single slot in the rack. Its dimensions measure 30.5 cm in length, 15.2 cm in width, and 3.2 cm in height.
Technical Specifications & Hardware Details
The GE IS200WEORG1A IS200WEORG1ACD features one high-speed processor for real-time turbine control. Two communication ports connect this board to the main controller and field devices. This board stores operational parameters in onboard flash memory. Five main components form the complete assembly: the PCB, the processor, the communication ports, the status LEDs, and the backplane connector.
| Parameter | Specification |
|---|---|
| Product Model | GE IS200WEORG1A IS200WEORG1ACD |
| Weight | 0.88 kg (1.94 lbs) |
| Dimensions (L×W×H) | 30.5 cm × 15.2 cm × 3.2 cm |
| Number of Components | 5 assemblies (PCB, processor, ports, LEDs, backplane connector) |
| Processor Speed | 400 MHz |
| Communication Ports | 2 × Ethernet (10/100 Mbps), 1 × RS-485 |
| Memory Type | 128 MB flash, 64 MB RAM |
| Memory Retention | Non-volatile flash (no battery needed) |
| Energy Storage | None (no batteries or capacitors) |
| Status Indicators | 4 front-panel LEDs (Power, Run, Fault, Comms) |
| Backplane Interface | Single 96-pin connector |
Wind Turbine Control Functions
You can configure this board to manage pitch angle and yaw positioning tasks. The dual Ethernet ports support redundant communication for critical turbine operations. For service access, connect a laptop to the RS-485 port for diagnostics. The GE IS200WEORG1A IS200WEORG1ACD also monitors generator temperature and vibration parameters.
Installation and Operational Environment
You can mount this board into any Mark VIe rack slot with proper alignment. The board draws 450 mA from the 24V DC supply during normal operation. Furthermore, it operates reliably within a -40°C to 70°C temperature range. Consequently, the GE IS200WEORG1A IS200WEORG1ACD requires no battery replacement over its lifetime. Just check the LED status indicators during routine turbine inspections.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
