Key Technical Specifications
This GE IS200VTURH2B IS200VTURH2BAC board operates from a 24V DC power supply. It provides 4 safety relay channels for turbine protection. The unit measures 23 cm in length, 17 cm in width, and 4.5 cm in height. Its total weight reaches 0.75 kg without any packaging materials.
The GE IS200VTURH2B IS200VTURH2BAC includes 4 force-guided safety relays for emergency trips. Additionally, it features one backplane connector for host communication. A single 6-pin terminal block connects the DC power input. The board contains 4 safety relays, 4 status LEDs, 4 snubber circuits, 1 watchdog timer, 12 resistors, and 10 capacitors.
| Parameter | Value |
|---|---|
| Power Supply | 24V DC ±10%, 200mA |
| Trip Channels | 4 independent |
| Relay Contact Rating | 5A at 240V AC / 30V DC |
| Response Time | < 10 ms |
| Dimensions (L x W x H) | 23 cm x 17 cm x 4.5 cm |
| Weight | 0.75 kg |
| Relay Type | Force-guided safety relays |
| Status LEDs | 4 units (red when tripped) |
| Power Indicator | 1 LED (green) |
| Backplane Interface | 50-pin DIN |
| Power Connector | 6-pin terminal block |
| Safety Relays | 4 units (force-guided) |
| Snubber Circuits | 4 RC networks |
| Watchdog Timer | 1 unit |
| Resistors | 12 units |
| Capacitors | 10 units |
| Energy Storage | 100 µF at 35V |
GE IS200VTURH2B IS200VTURH2BAC stores energy using one electrolytic capacitor. This capacitor provides 100 µF at 35V rating for relay hold-up. Consequently, the board maintains trip outputs during 25 millisecond power interruptions. Therefore, safety trips remain active through brief voltage dips.
Design and Integration
Both the GE IS200VTURH2B and IS200VTURH2BAC versions share identical safety circuit topology. These boards use four-layer PCB construction with force-guided relay contacts for safety compliance. Consequently, the GE IS200VTURH2B IS200VTURH2BAC operates reliably from -10°C to +55°C ambient temperature.
For installation, you need M3 screws for the four mounting holes. The board draws 150 mA typical current from the 24V DC supply. Each safety relay includes positive-guided contacts for diagnostic coverage. We recommend using 18 AWG wire for all trip output connections.
Practical Application
This turbine protection circuit board initiates turbine shutdown upon detecting critical faults. It receives trip commands from overspeed and vibration protection systems. The GE IS200VTURH2B IS200VTURH2BAC then opens safety relays to de-energize trip solenoids. Therefore, it provides reliable emergency protection for GE turbine control systems.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
