The GE IS200TBAIH1C IS200TBAIH1CED serves as a dedicated analog input terminal board for Mark VIe systems. It connects field sensors directly to the turbine controller. Therefore, it guarantees accurate signal acquisition for power generation plants.
Technical Specifications of GE IS200TBAIH1C IS200TBAIH1CED
This board measures 25.4 cm in length and 17.8 cm in width. Its total weight stays below 0.5 kg for straightforward handling. A single 64-pin female connector links the board to the main controller. Additionally, thirty-two screw terminal blocks handle all field wiring tasks.
| Parameter | Specification |
|---|---|
| Brand | General Electric (GE) |
| Full Model | IS200TBAIH1C IS200TBAIH1CED |
| Category | Analog Input Terminal Board |
| Dimensions (L x W) | 25.4 cm x 17.8 cm (10.0″ x 7.0″) |
| Board Weight | 0.45 kg (0.99 lbs) |
| Primary Interface | 1 x 64-pin Female Connector |
| Field Wiring Points | 32 Screw Terminal Blocks |
| Analog Input Channels | 16 Differential Channels |
| Input Signal Range | 0-10 VDC or 4-20 mA (Jumper Selectable) |
| On-Board Components | 2 Signal Conditioners + 1 Filter Array |
| Energy Storage | 4 x 220 µF Electrolytic Capacitors |
| Operating Voltage | +5 VDC from Backplane |
| Isolation Rating | 1500 Vrms (Channel to Backplane) |
Energy Storage and Signal Integrity
The GE IS200TBAIH1C IS200TBAIH1CED stores energy using four electrolytic capacitors. These capacitors provide smooth filtering for all incoming analog signals. Each unit discharges naturally during a power-down event. This feature protects downstream circuits from sudden voltage spikes.
Installation and Mechanical Layout
You will find thirty-two screw terminals arranged along two board edges. These terminals accept 12-22 AWG copper wires securely. The board also includes four mounting holes for standoff installation. Consequently, this terminal board fits standard DIN rails with an adapter plate.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
