The GE IS200TBAIH1C IS200TBAIH1CDC Terminal Board terminates analog input signals for Mark VI turbine systems. You will find this board in industrial generator control panels worldwide. It provides a reliable connection between field sensors and the main controller.

Technical Specifications

The GE IS200TBAIH1C IS200TBAIH1CDC Terminal Board carries its revision clearly on the PCB edge. This board measures 305 mm in length and 178 mm in width. Its total height reaches 30 mm including terminal blocks. The card weighs approximately 0.65 kg (1.43 lbs). Transition words like first and then help describe its signal routing. First, the board accepts 32 analog input wires through screw terminals. Then, it passes these signals through a 50-pin ribbon cable header. Finally, onboard RC filters remove high-frequency noise from each channel.

Hardware Parameters

The table below lists all critical technical details for this module.

Functional Features

The GE IS200TBAIH1C IS200TBAIH1CDC Terminal Board includes a 330 µF capacitor bank for signal stabilization. This storage also provides 15 ms of hold-up for analog circuits. Additionally, each screw terminal has a numbered label for quick identification. Moreover, gold-plated header pins prevent corrosion in humid environments. You can mount this board on any standard DIN rail or backplate.

Installation and Compatibility

This board replaces older revisions like IS200TBAIH1B without wiring modifications. Always torque terminal screws to 0.5 Nm for secure connections. The GE IS200TBAIH1C IS200TBAIH1CDC Terminal Board requires a matching ribbon cable to the analog I/O card. Verify proper grounding before you apply power to the system.
