The GE IS200EXHSG1A IS200EXHSG1AEB Printed Circuit Board handles high-speed exciter signals for Mark VI systems. You will find this board in generator excitation control panels and power plants. It provides reliable signal conditioning between static exciters and the main controller.
Technical Specifications
The GE IS200EXHSG1A IS200EXHSG1AEB Printed Circuit Board carries its revision clearly on the PCB edge. This board measures 305 mm in length and 178 mm in width. Its total height reaches 30 mm including connector housings. The card weighs approximately 0.74 kg (1.63 lbs). Transition words like first and then help describe its signal flow. First, the board accepts 32 field wiring points through barrier terminals. Then, it routes these signals through onboard buffer circuits. Finally, the board transmits clean data through a 50-pin ribbon cable header.
Hardware Parameters
The table below lists all critical technical details for this module.
| Parameter | Value |
|---|---|
| Full Model | GE IS200EXHSG1A IS200EXHSG1AEB |
| Category | High-Speed Exciter PCB |
| Dimensions | 305 mm x 178 mm x 30 mm |
| Weight | 0.74 kg (1.63 lbs) |
| Terminal Blocks | 32 barrier-type positions |
| Interface Connectors | One 50-pin ribbon cable header |
| Component Count | 162 discrete components |
| Energy Storage | 2200 µF capacitor bank |
| Voltage Rating | 600V DC maximum per terminal |
| Current Rating | 8A continuous per terminal |
| Response Time | 1.5 ms typical for signal propagation |
| Operating Temp | -30°C to +70°C |
| Isolation | 4 optocouplers for channel separation |
| LED Indicators | Power (green) and activity (yellow) |
Functional Features
The GE IS200EXHSG1A IS200EXHSG1AEB Printed Circuit Board includes a 2200 µF capacitor bank for noise filtering. This storage also provides 60 ms of brownout protection for critical circuits. Additionally, each barrier terminal accepts wire gauges from 12 to 22 AWG. Moreover, gold-plated contacts on the ribbon header prevent signal corrosion. You can mount this board vertically in any Mark VI exciter cabinet.
Installation and Compatibility
This board replaces older revisions like IS200EXHSG1A without hardware changes. Always torque barrier screws to 0.7 Nm for reliable long-term connections. The GE IS200EXHSG1A IS200EXHSG1AEB Printed Circuit Board requires a matching ribbon cable to the exciter controller. Verify proper grounding before you power up the system.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
