Product Overview
This I/O regulator board manages voltage distribution for turbine control systems. You can install GE IS200EGPAG1B IS200EGPAG1BEC in Mark VIe racks directly. The board ensures stable power for connected field devices. Its compact design fits standard industrial cabinets without modification.
Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions (W x H x D) | 180 mm x 105 mm x 25 mm |
| Weight | 0.38 kg |
| I/O connector type | Two 20-pin header connectors |
| Total onboard components | 62 discrete parts |
| Energy storage type | Tantalum capacitors |
| Energy storage rating | 330 µF at 16V DC |
| Input voltage range | 18–30V DC (nominal 24V) |
| Operating temperature | -30°C to +65°C |
Design and Layout
A six-layer PCB reduces electromagnetic interference effectively. Each regulator channel features independent overcurrent protection. Additionally, tantalum capacitors provide 330 µF of energy storage. The board releases stored energy below 3V within eight seconds. This rapid discharge enhances technician safety during maintenance.
Installation Requirements
You can mount GE IS200EGPAG1B IS200EGPAG1BEC on a 35 mm DIN rail. The board connects directly to GE IS200 series backplanes. It also accepts 24V DC inputs from third-party controllers. Consequently, integration takes minimal effort and time.
Performance Characteristics
Output ripple stays below 50 mV peak-to-peak under full load. Therefore, sensitive sensors receive clean, stable power. The passive heatsink dissipates all thermal energy effectively. You do not need external cooling fans for operation.
Compliance and Safety
This regulator board meets CE and UL 508A standards. Its capacitors self-discharge to safe levels quickly. Hence, field technicians face lower electrical risks during repairs.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
