The IC752DSX000-DD DataPanel operator interface delivers visual monitoring and control for GE industrial automation systems. This unit combines a color display, touch input, and communication ports in one panel. Operators depend on it for machine status viewing and process adjustment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Operator Interface Panel |
| Compatibility | GE Fanuc Automation Controllers |
| Display Type | Color LCD, 10.4 Inch TFT |
| Display Resolution | 640 x 480 Pixels |
| Input Method | Resistive Touchscreen |
| Interface | Serial Port, Ethernet, Backplane Connector |
| Dimensions | 300 mm x 220 mm x 65 mm |
| Weight | Approximately 1.80 kg |
| Component Count | 68 Active Electronic Components |
| Energy Storage | 3.6 V Lithium Backup Battery |
| Power Consumption | 24 VDC at 1.2 A |
| Operating Temperature | 0°C to 50°C |
| Relative Humidity | 5% to 95%, Non-Condensing |
Display and Touch Performance
The 10.4-inch TFT screen shows 640 x 480 pixel graphics with clear color rendering. Therefore, operators read process diagrams and alarm screens without strain. Furthermore, the resistive touchscreen responds to gloved hands and stylus input. Consequently, it suits harsh factory environments.
Communication and Integration
Serial and Ethernet ports link the IC752DSX000-DD to controllers and plant networks. As a result, data moves between the panel and host systems efficiently. Additionally, a backplane connector supports direct rack integration where needed.
Power and Backup
The panel draws 24 VDC at 1.2 A from a standard industrial supply. Moreover, a 3.6 V lithium battery preserves screen configurations during outages. Consequently, technicians avoid rebuilding displays after short interruptions.
Installation Notes
Operators mount the unit through a standard panel cutout for flush fitting. The sealed front bezel resists dust and moisture in production areas. However, users should confirm cutout dimensions before drilling mounting holes.
Details
| Weight | 1.5 kg |
|---|---|
| Dimensions | 278 × 194 × 42 mm |
