The IC697PWR710B delivers regulated DC power inside GE Fanuc’s Series 90-70 PLC platform. This module measures roughly 11.5 inches tall, 2.0 inches wide, and 8.0 inches deep. Moreover, it weighs about 4.0 pounds, which suits standard rack installation. Engineers specify the IC697PWR710B when they need stable rail voltages for processors and I/O modules.
Technical Specifications and Interface Details
The unit converts AC mains input into regulated DC output for backplane distribution. Specifically, it supplies 5 VDC and 24 VDC rails to connected Series 90-70 modules. Additionally, screw terminals accept field wiring without special tools. Front-panel LEDs reveal output status and fault conditions during service.
| Parameter | Specification |
|---|---|
| Module Type | Power Supply Module |
| Platform | Series 90-70 PLC |
| Input | AC mains |
| Output | 5 VDC and 24 VDC rails |
| Dimensions | 11.5 x 2.0 x 8.0 in |
| Weight | ~4.0 lbs |
| Terminals | Screw-type field connections |
| Mounting | Series 90-70 rack |
Energy Storage and Output Stability
Internal capacitors on the IC697PWR710B provide substantial energy storage for smooth DC output. Consequently, the supply rides through brief mains dips without disturbing logic circuits. This buffering also filters ripple that could affect analog measurements. The design therefore supports consistent performance across demanding plant conditions.
Installation and Compatibility Notes
Because the IC697PWR710B slides into standard Series 90-70 racks, technicians finish installation quickly. They should verify mains voltage before they energize the supply. Furthermore, the module integrates smoothly with existing 90-70 control hardware. Always store spare units in anti-static packaging to protect sensitive components.
Details
| Weight | 1.5 kg |
|---|---|
| Dimensions | 278 × 194 × 42 mm |
