Product Overview
The GE IC697MDL750 discrete output module drives 16 output channels for controlling actuators and indicators in GE Fanuc Series 90-70 systems. This module delivers robust switching performance with 24V DC nominal voltage. It integrates seamlessly with the Series 90-70 backplane. The unit provides reliable output control for industrial automation applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IC697MDL750 |
| Product Type | Discrete Output Module |
| Brand | GE Fanuc |
| Category | PLC Output Modules |
| Number of Outputs | 16 channels |
| Nominal Voltage | 24V DC |
| Output Current | 2.0 A per channel (max) |
| Output Type | Transistor switching |
| Short-Circuit Protection | Yes (per channel) |
| Backplane Current Draw | 5V DC, 300 mA |
| Weight | Approximately 0.32 kg |
| Dimensions | Standard Series 90-70 module |
| Operating Temperature | 0°C to 60°C |
| Protection Class | IP20 |
Key Features and Benefits
High-Current Output Capability
The IC697MDL750 delivers up to 2.0 A per channel for demanding loads. This capacity drives solenoids, contactors, and other high-current devices directly. Users can eliminate costly interposing relay panels in many cases.
Built-In Channel Protection
Each output channel features independent short-circuit protection. This built-in safety prevents module damage from wiring faults. Operators benefit from reduced downtime and fewer component failures.
Diagnostic Feedback
The module reports output status to the CPU for real-time monitoring. This feedback enables rapid fault identification and resolution. Engineers can maintain system reliability effectively.
Application and Use Cases
The GE IC697MDL750 serves conveyor control, packaging machinery, and material handling systems. It also drives actuators in process control applications. Maintenance teams will find this module an ideal replacement for failed output units.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
