Product Overview
The GE IC697CMM742 provides high-speed Ethernet connectivity for the GE 90-70 PLC system. This communication module enables seamless integration with plant-wide control networks and enterprise systems. Industrial facilities depend on this interface for reliable data exchange between controllers and supervisory software. The module’s robust TCP/IP stack ensures stable performance in demanding manufacturing environments.
Technical Specifications
This Ethernet interface module features a dedicated communications processor for efficient data handling. The GE IC697CMM742 supports multiple industrial protocols including SRTP and Modbus TCP/IP. Its dual RJ-45 ports provide network redundancy and switch connectivity. The module’s advanced diagnostics suite allows comprehensive network health monitoring.
| Parameter | Specification |
|---|---|
| Product Type | Ethernet Communication Interface Module |
| Series Compatibility | GE 90-70 PLC Series |
| Processor | Dedicated 32-bit communications coprocessor |
| Number of Ports | 2 x RJ-45 (10/100BASE-TX) |
| Network Protocols | SRTP, Modbus TCP/IP, EGD, SNMP, HTTP, FTP |
| Data Rate | 10/100 Mbps (auto-negotiating) |
| Network Topology | Star, daisy-chain (switch-dependent) |
| Maximum Connections | 16 simultaneous active connections |
| Memory | 4 MB flash for firmware; 2 MB RAM for buffers |
| Energy Storage | EEPROM retains configuration without power |
| Diagnostics | Link status, traffic counters, error logs, PING utility |
| LED Indicators | Link/Activity, Status, Fault, Power |
| Power Supply | 5 V DC from backplane |
| Current Consumption | Maximum 0.65 A |
| Dimensions (W x H x D) | 25 mm x 130 mm x 110 mm |
| Weight | Approximately 0.35 kg |
| Connector Type | Two shielded RJ-45 sockets |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH (non-condensing) |
Communication Capabilities
The GE IC697CMM742 supports both client and server modes for versatile integration. Its Ethernet Global Data (EGD) feature enables peer-to-peer data sharing between multiple PLCs. The module also provides web server functionality for remote status monitoring via standard browsers. Users can exchange data with SCADA systems and manufacturing execution systems seamlessly.
Protocol Support
This interface module handles multiple protocols simultaneously for maximum flexibility. The GE IC697CMM742 supports SRTP for native GE communications and Modbus TCP/IP for third-party device integration. Its embedded FTP server allows file transfers for firmware updates and data logging. The module also includes SNMP for network management system integration.
Diagnostics and Network Monitoring
The GE IC697CMM742 offers comprehensive network diagnostics and performance monitoring tools. Its PING utility tests network connectivity to remote devices. The module logs communication errors for later troubleshooting. Users can monitor network traffic statistics through programming software.
Application Scenarios
System integrators deploy this module for connecting 90-70 PLCs to plant-wide Ethernet networks. It also interfaces with remote I/O racks and operator workstations. The GE IC697CMM742 provides robust Ethernet communication for industrial control systems.
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 25 × 130 × 110 mm |
