Series 90-70 Genius Bus Controller Module
The IC697BEM733 functions as a communication interface module for the GE Series 90-70 PLC system. This module connects the main controller to the Genius I/O network. It manages data exchange between multiple remote I/O stations. The unit also handles network diagnostics and fault reporting.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | GE |
| Model | IC697BEM733 |
| Category | Communication Interface Module |
| System Compatibility | Series 90-70 PLC |
| Network Type | Supports Genius LAN interface |
| Communication Speed | Operates at 153.6 kbps nominal |
| Cable Type | Accepts twisted-pair or fiber optic cables |
| Node Capacity | Supports up to 32 Genius devices |
| Data Exchange | Transfers 128 bytes per scan |
| Power Supply | Draws +5 Vdc at 1.0 A maximum |
| Diagnostics | Includes built-in network monitoring |
| Status Indicators | Features LAN OK and module OK LEDs |
| Isolation | Provides 1500 Vac optical isolation |
| Operating Temperature | Functions from 0°C to +60°C |
| Storage Temperature | Withstands -40°C to +85°C |
| Dimensions | Measures 125.0 mm x 64.0 mm x 80.0 mm |
| Weight | Weighs approximately 0.4 kg |
| Mounting | Plugs into Series 90-70 rack slots |
| Compliance | Meets CE, UL, and CSA standards |
Network Communication Capabilities
This interface module enables seamless communication between the PLC and remote I/O blocks. It supports both twisted-pair and fiber optic physical media. The module also handles automatic baud rate detection for simple installation. Furthermore, it continuously monitors network integrity and reports any communication faults. The unit’s compact design minimizes rack space consumption.
Installation and Configuration
First, insert the IC697BEM733 into an available slot within the 90-70 rack. Ensure the module locks firmly into the backplane connector. Next, connect the Genius network cable to the designated port. After that, apply power and observe the status LED indicators. You can then configure the module parameters using the programming software.
Maintenance and Operational Integrity
This module includes comprehensive diagnostics to simplify troubleshooting. Therefore, you can quickly identify network communication problems. We recommend you monitor the LAN OK indicator during system operation. You should also inspect the cable connections for any signs of wear periodically.
Details
| Weight | 0.4 kg |
|---|---|
| Dimensions | 125 × 64 × 80 mm |
