This Ethernet interface module provides high-speed network connectivity for GE RX3i PACSystems controllers. It enables seamless data exchange between the control system and plant-wide networks. The IC695ETM001-HT supports extended temperature operation for harsh industrial environments.
Core Communication Specifications
The module features two independent 10/100/1000 Mbps Ethernet ports for redundant network architectures. It supports both TCP/IP and UDP/IP protocols for flexible communication options. Furthermore, the unit handles up to 96 simultaneous connections for versatile networking. The module supports SRTP, Modbus TCP, and EGD protocols for broad compatibility. It achieves data transfer rates of up to 1000 Mbps for fast exchange.
Connectivity and Network Features
The front panel provides two RJ45 connectors with integrated link and activity status LEDs. These connectors support auto-negotiation and auto-MDI/MDIX for easy cabling. Additionally, the IC695ETM001-HT includes a dedicated service port for diagnostics and configuration. A multi-color LED array indicates network speed, activity, and fault conditions clearly. Engineers can configure the module using standard web browser interfaces.
Extended Temperature and Environmental Design
The module operates reliably across a temperature range of -40°C to +75°C. This extended range suits outdoor and unheated equipment enclosures perfectly. Furthermore, the IC695ETM001-HT employs conformal-coated PCBs to resist moisture and airborne contaminants. The unit withstands vibration up to 2 g across 10–500 Hz frequencies. It also includes transient voltage suppression for protection against power surges.
Mechanical Specifications and Installation Details
The module measures 22.5 x 14.0 x 4.5 centimeters and weighs approximately 650 grams. Its single-slot design occupies minimal space in GE RX3i standard racks. The operating humidity range spans 5% to 95% non-condensing for versatile deployment. Moreover, the IC695ETM001-HT features gold-plated edge connectors for reliable backplane contact.
Technical Parameters Summary
| Parameter | Specification |
|---|---|
| Model | GE IC695ETM001-HT |
| Network Ports | 2 x 10/100/1000 Mbps RJ45 |
| Protocols Supported | SRTP, Modbus TCP, EGD, TCP/IP, UDP/IP |
| Simultaneous Connections | 96 maximum |
| Data Transfer Rate | Up to 1000 Mbps |
| Auto-Negotiation | Supported on both ports |
| Service Port | Dedicated diagnostic port |
| Status LEDs | Multi-color (speed, activity, fault) |
| Configuration | Web browser interface |
| Operating Temperature | -40°C to +75°C |
| PCB Coating | Conformal-coated |
| Vibration Tolerance | 2 g, 10–500 Hz |
| Surge Protection | Transient voltage suppression |
| Dimensions (W x H x D) | 22.5 x 14.0 x 4.5 cm |
| Weight | 650 g |
| Humidity Range | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA |
System Integration and Application Areas
This Ethernet module integrates with GE RX3i and RX7i PACSystems controllers. It enables communication with SCADA systems, HMIs, and enterprise networks effectively. The module’s dual-port design supports daisy-chaining and ring topologies for redundancy. Industries such as oil and gas, mining, and outdoor water treatment benefit from its extended temperature range.
Summary
The IC695ETM001-HT provides robust Ethernet connectivity for demanding industrial automation environments. Its high-speed ports, wide temperature tolerance, and versatile protocol support ensure reliable networking. This module offers a dependable communication backbone for PACSystems installations.
Details
| Weight | 0.65 kg |
|---|---|
| Dimensions | 225 × 140 × 45 mm |
