This analog output module converts digital commands into precise DC voltage signals for field devices. The GE IC693MDL741 provides two isolated output channels with 12-bit resolution. Each channel generates an output voltage range of 0 to +10 VDC or -10 to +10 VDC. The module drives loads up to 5 mA per channel for standard actuator and indicator inputs. It includes built-in self-calibration circuitry to maintain accuracy over temperature changes.
Mechanical Dimensions and Construction Quality
The module measures 110 mm in height, 85 mm in depth, and 45 mm in width. This compact footprint integrates easily into the Series 90-30 rack system. Weighing only 0.32 kg, the IC693MDL741 simplifies handling during installation and maintenance. A rugged thermoplastic housing provides reliable protection against dust and mechanical damage. This housing meets IP20 requirements for safe indoor panel mounting.
Technical Specifications at a Glance
| Specification | Detail |
|---|---|
| Output Channels | 2 (isolated, unipolar/bipolar selectable) |
| Resolution | 12-bit (4096 steps) |
| Voltage Range | 0 to +10 VDC or -10 to +10 VDC |
| Output Current | 5 mA maximum (per channel) |
| Load Impedance | ≥ 2 kΩ (for rated accuracy) |
| Accuracy | ±0.25% of full scale (25 °C) |
| Settling Time | 5 ms (to 0.1% of final value) |
| Dimensions (H × W × D) | 110 mm × 45 mm × 85 mm |
| Weight | 0.32 kg |
| Terminal Block | 10‑position screw clamp |
| Wire Gauge Range | 0.2 – 2.5 mm² |
| Backplane Current | 120 mA at 5 VDC |
| External Supply | 24 VDC ±10% |
| Power Dissipation | 2.4 W |
| Isolation Voltage | 1500 VAC (channel‑to‑bus) |
| Energy Buffer | 47 µF capacitor (5 ms hold‑up) |
| Temperature Range | 0 °C to +60 °C |
| Humidity Range | 5% – 95% RH (non‑condensing) |
| Standards | UL 508, CSA, CE |
| Protection Rating | IP20 |
| Diagnostics | LED indicators (PWR, CH1, CH2, FAULT) |
Interface and Connectivity Features
A 10‑position screw clamp terminal block provides reliable field wiring connections for both channels. This terminal block accepts solid or stranded wires from 0.2 to 2.5 mm². Each channel includes dedicated shield terminals for cable screening and noise reduction. Front‑panel LEDs display channel status, supply presence, and fault conditions clearly. The module integrates directly into the Series 90‑30 backplane for high‑speed data exchange.
Power Architecture and Energy Storage
The GE IC693MDL741 draws 120 mA from the 5 VDC backplane for internal logic operations. It also requires a 24 VDC ±10% external supply for the analog output circuitry. An onboard 47 µF capacitor provides short‑term energy storage for signal stability. This capacitor maintains output voltages during power dips lasting up to 5 milliseconds. Total power dissipation stays at a low 2.4 W under full load.
Internal Component Architecture
A 12‑bit multiplying DAC converts digital values into precise analog voltages for each channel. Two independent output amplifiers buffer the signals for load driving capability. The module includes precision voltage reference with 25 ppm/°C temperature stability. The PCB contains 64 surface‑mount resistors, 48 ceramic capacitors, and 2 operational amplifiers. A self‑calibration routine adjusts gain and offset automatically at startup. Each channel uses optocoupler isolation to protect the controller from field transients.
Environmental Performance and Certifications
This analog output module operates reliably from 0 °C to +60 °C in factory conditions. It also performs consistently in humidity levels from 5% to 95% without condensation. The IC693MDL741 complies with UL 508, CSA, and CE certification standards. These approvals ensure safe integration into global industrial control applications.
Details
| Weight | 0.32 kg |
|---|---|
| Dimensions | 110 × 45 × 85 mm |
