I/O modules

Product Overview

This logic input module accepts both positive and negative DC signals from field devices. It interfaces directly with the Series 90-30 programmable controller for flexible system integration. The IC693MDL654 converts 24 VDC inputs into logic-level signals for the CPU. It features sixteen isolated input points in a compact form factor. Users can configure each channel independently for sourcing or sinking field devices.

Technical Specifications

The IC693MDL654 measures 12.5 cm in height and 11.4 cm in depth with standard Series 90-30 dimensions. It weighs approximately 0.34 kg, making it easy to install in dense rack configurations. This module draws 150 mA from the +5 VDC backplane supply and requires an external 24 VDC field supply. It provides sixteen discrete input channels with a nominal voltage rating of 24 VDC. The input voltage range spans from 0 to 30 VDC for robust signal compatibility. Each channel exhibits an on-state threshold of 10 VDC minimum and an off-state threshold of 3 VDC maximum. The input current per point measures 7 mA typical at rated voltage. The module responds to signal changes within 2 ms for high-speed applications. It also features optical isolation of 1500 VAC for backplane protection.

Logic Configuration and Operation

This module supports both positive logic (sourcing) and negative logic (sinking) field devices. It accepts signals from PNP sensors with positive logic or NPN sensors with negative logic. The IC693MDL654 includes a configurable common terminal for each bank of eight inputs. Users can wire the common to either +24 VDC or 0 VDC depending on the sensor type. The module automatically adapts to the selected logic configuration without jumpers.

Physical and Electrical Parameters

Installation and Configuration

Install the IC693MDL654 into any available slot within the Series 90-30 I/O rack. Secure the module using the retaining screws at both top and bottom positions. Connect the external 24 VDC supply to the designated power terminals on the module. Wire each field device to its corresponding input channel with proper polarity. Configure the common terminals for either positive or negative logic based on your sensor type. The CPU automatically detects the module and assigns input addresses upon power-up. You can monitor channel status through the front-panel LEDs.

Typical Applications

This module serves machine control, conveyor systems, and material handling equipment. It accepts signals from photoelectric sensors, inductive proximity switches, and limit switches. The IC693MDL654 also interfaces with pushbuttons, selector switches, and relay contacts. Its dual-logic capability makes it suitable for mixed sensor installations.
