The IC693CPU323U central processing unit drives logic execution for GE Series 90-30 PLC systems. This CPU combines program memory, communication ports, and I/O scanning in one module. Engineers depend on it for dependable control across manufacturing and process applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Central Processing Unit |
| Compatibility | GE Series 90-30 PLC Systems |
| Processor | 32-Bit Microprocessor |
| Program Memory | 32 KB User Logic, Expandable |
| Interface | Backplane Bus, Serial Port, SNP Protocol |
| Dimensions | 130 mm x 50 mm x 110 mm |
| Weight | Approximately 0.40 kg |
| Component Count | 56 Active Electronic Components |
| Energy Storage | 3.0 V Lithium Backup Battery |
| Power Consumption | 5 VDC at 0.9 A |
| Operating Temperature | 0°C to 60°C |
| Relative Humidity | 5% to 95%, Non-Condensing |
Processing and Memory Architecture
The module runs a 32-bit microprocessor with 32 KB of user logic space. Therefore, it executes ladder and instruction list programs at fast scan rates. Furthermore, memory expansion options support larger control applications. Consequently, one CPU covers many system requirements.
Communication and Interface
A serial port supports SNP protocol for programming and peer data exchange. Moreover, the backplane bus links the IC693CPU323U to local I/O modules. As a result, scan cycles stay deterministic across the entire rack.
Power and Backup
The unit draws 5 VDC at 0.9 A from the system power supply. Additionally, a 3.0 V lithium battery preserves program memory during outages. Consequently, technicians avoid reloading logic after brief interruptions.
Installation Notes
Operators insert the module into a standard Series 90-30 rack slot. The compact housing occupies one slot, conserving valuable chassis space. However, users should confirm firmware revision before commissioning the system.
