This CPU module serves as the central processor for GE Fanuc Series 90-30 programmable controllers. It executes logic programs and manages system I/O for industrial automation tasks. Engineers choose this module for its processing power and flexible memory options. Its design suits both OEM machinery and plant-floor control applications.

Processing Architecture and Memory Configuration

The GE IC693CPU311D offers 32 KB of user program memory for logic execution. Its scan time reaches 0.3 ms per 1K of logic for fast processing. This module supports a maximum of 128 discrete I/O points and 32 analog I/O points. The built-in power supply provides 30W of output at 5 VDC. Additionally, the module features a battery-backed memory that retains programs during power outages. The battery provides approximately 1000 days of retention for user programs.

Communication Ports and Connectivity

The GE IC693CPU311D features one RS-232 serial port for programming and data exchange. This port supports SNP, RTU, and SNPX protocols for flexible communication . Engineers can connect programming software for real-time monitoring and configuration. Additional data exchange functions allow integration with HMIs and SCADA systems. Therefore, this module supports various industrial communication requirements.

Key Technical Specifications

The table below summarizes the critical parameters for the GE IC693CPU311D.

Installation and System Integration

This CPU module occupies one slot in a 90-30 Series baseplate . Users can expand the system by adding I/O modules in adjacent slots. The module mounts easily using the integrated locking mechanism. Diagnostic LED indicators display RUN, STOP, and fault conditions for troubleshooting. Consequently, technicians can maintain systems efficiently with clear status feedback.
