The IC670MDL640B input module captures discrete field signals for GE Field Control and Genius distributed I/O systems. This unit converts switch, sensor, and contact states into digital data. Engineers rely on it for dependable status monitoring across factory automation networks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Discrete Input Module |
| Compatibility | GE Field Control and Genius I/O Systems |
| Input Channels | 16 Discrete Inputs |
| Input Voltage | 24 VDC |
| Input Current | 7 mA Per Point at Rated Voltage |
| Interface | Backplane Bus Connector, Front Terminal Block |
| Dimensions | 130 mm x 50 mm x 105 mm |
| Weight | Approximately 0.32 kg |
| Component Count | 48 Active Electronic Components |
| Energy Storage | None Required |
| Power Consumption | 5 VDC at 0.6 A |
| Operating Temperature | 0°C to 60°C |
| Relative Humidity | 5% to 95%, Non-Condensing |
Input Performance and Signal Handling
The module offers 16 discrete input points for switch and sensor monitoring. Therefore, it reads field contact states without external signal conditioning. Furthermore, each point draws roughly 7 mA at the rated 24 VDC level. Consequently, it interfaces directly with most industrial pilot devices.
Interface and Integration
A backplane connector links the IC670MDL640B to the distributed I/O rack. As a result, input status travels to the controller through protected internal paths. Additionally, the front terminal block simplifies field wiring and troubleshooting.
Power and Protection
The unit draws 5 VDC at 0.6 A from the system power supply. Moreover, internal filtering rejects electrical noise from nearby drive equipment. Consequently, connected signals remain stable in electrically noisy plants.
Installation Notes
Operators insert the module into a standard Field Control rack slot. The single-slot housing conserves chassis space for additional I/O modules. However, users should verify input voltage levels before commissioning the rack.
