The IC660TSD100 terminal assembly from GE Fanuc provides a secure wiring interface for Genius I/O blocks and industrial control panels. Technicians install this assembly wherever field cables must land reliably on a compact terminal base. Consequently, it simplifies wiring, speeds up maintenance, and keeps field connections stable under vibration.
Key Technical Specifications
The table below summarizes the main physical and electrical parameters of the IC660TSD100 assembly.
| Parameter | Specification |
|---|---|
| Product Type | Terminal Assembly |
| Compatibility | GE Fanuc Genius I/O systems |
| Dimensions | Approximately 150 mm x 89 mm x 40 mm |
| Weight | Approximately 0.4 kg (0.88 lbs) |
| Mounting | Panel or baseplate mounting |
| Interface | Screw terminal field connections |
| Connectors | Multiple screw terminal positions |
| Component Count | Terminal blocks, retaining hardware, and labeling plates |
| Energy Storage | Filter capacitors for signal smoothing |
| Terminal Count | Multiple field wiring positions |
| Operating Temperature | 0 degrees C to 60 degrees C |
| Storage Temperature | -40 degrees C to 85 degrees C |
| Humidity | 5% to 95% non-condensing |
Functional Overview
This assembly accepts field wires and routes each signal to the correct I/O channel. Therefore, it keeps cable management clean during installation and retrofit projects. The IC660TSD100 also provides a stable mechanical anchor that resists vibration loosening. Meanwhile, its onboard energy storage smooths low-level signals against electrical noise.
Installation and Handling Notes
Always strip field wires to the recommended length before inserting them. In addition, tighten each screw terminal to the specified torque value. Verify channel mapping against your loop drawings before powering the cabinet. Finally, label every terminal clearly for future maintenance work.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
