The IC660TBA105 provides field wiring termination inside GE Fanuc’s Genius I/O platform. This terminal assembly measures roughly 7.5 inches long, 3.5 inches wide, and 2.0 inches high. Moreover, it weighs about 1.0 pound, which suits panel and rack mounting. Engineers select the IC660TBA105 when they need secure screw terminations for distributed I/O blocks.
Technical Specifications and Interface Details
The assembly carries screw terminals that accept field wiring from sensors and actuators. Specifically, it supports multiple termination points with clearly labeled positions. Additionally, a keyed connector mates the assembly to the host I/O block. The housing shields contacts from dust and accidental contact.
| Parameter | Specification |
|---|---|
| Module Type | Terminal Assembly |
| Platform | Genius I/O |
| Terminals | Screw-type field connections |
| Dimensions | 7.5 x 3.5 x 2.0 in |
| Weight | ~1.0 lb |
| Connector | Keyed mating connector |
| Mounting | Panel or rack |
| Housing | Dust-shielded enclosure |
Energy Storage and Signal Integrity
Internal filtering components on the IC660TBA105 provide local energy storage for clean signal paths. Consequently, the assembly suppresses noise that could disturb I/O readings. This buffering keeps field signals stable in electrically busy cabinets. The design therefore supports consistent measurement accuracy across long service intervals.
Installation and Compatibility Notes
Because the IC660TBA105 mates directly with Genius I/O blocks, technicians complete installation quickly. They should verify terminal assignments before they connect field wiring. Furthermore, the assembly accepts a range of Genius I/O modules. Always store spare units in anti-static packaging to protect sensitive components.
Details
| Weight | 1.5 kg |
|---|---|
| Dimensions | 278 × 194 × 42 mm |
