Terminal Assembly for Genius I/O Analog Output Blocks
The GE IC660TBA026 serves as a terminal assembly for the GE Fanuc Genius I/O system. This assembly provides the physical connection point for field wiring to the analog output block. Its design simplifies installation and maintenance in distributed control applications.
Connection and Wiring Features
This terminal assembly connects directly to the IC660EBA026 analog output block via a dedicated interface . It features six inputs that accommodate 4 to 20 mA signals for industrial instrumentation . The assembly supports both 115 VAC and 125 VDC input voltage ratings. Furthermore, its screw-type terminals provide secure and reliable wire connections. Consequently, this assembly simplifies field wiring and reduces installation time.
Diagnostic and Protection Capabilities
The IC660TBA026 includes enhanced diagnostic features for reliable operation. It can detect over-range and under-range conditions in the output signal . The assembly alerts operators when output feedback falls below 1.5 mA. Moreover, it provides output hold-last-state functionality for fault conditions. For this reason, operators can maintain control during temporary communication interruptions.
Physical Specifications and Environmental Ratings
This terminal assembly features compact dimensions of 8.83 x 3.50 x 3.94 inches (H x W x D) . The unit dissipates 12 Watts of heat during normal operation. It operates reliably from 0 °C to 60 °C ambient temperature. Additionally, the storage temperature range extends from -40 °C to 100 °C. Consequently, this assembly suits harsh industrial environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | IC660TBA026 |
| Type | Terminal Assembly |
| Series | Genius I/O |
| Manufacturer | GE Fanuc |
| Input Channels | 6 |
| Signal Type | 4-20 mA |
| Input Voltage | 115 VAC / 125 VDC |
| Output Accuracy | 0.15% at 25 °C |
| Heat Dissipation | 12 W |
| Weight | 0.60 kg (approx.) |
| Dimensions (H x W x D) | 8.83 x 3.50 x 3.94 in |
| Operating Temp | 0 °C to 60 °C |
| Storage Temp | -40 °C to 100 °C |
| Compliance | UL 508, CSA C22.2, IEC 60947-1 |
