Functional Overview
The IC660BBD025 operates as a high-density 32-circuit sink I/O block within the GE Genius I/O system. This module handles both input and output functions on each of its 32 circuits. It provides flexible configuration for sourcing or sinking field devices. The block automatically detects the connected voltage type during power-up. Consequently, it simplifies system design and reduces spare parts inventory significantly.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Series | Genius I/O |
| Category | I/O Block |
| Part Number | IC660BBD025 |
| Number of Circuits | 32 (configurable as inputs or outputs) |
| Input Voltage Range | 24 VDC (nominal), 10-30 VDC (operating) |
| Output Current | 0.5 A per circuit (maximum) |
| Total Output Current | 8 A (all outputs combined) |
| Input Current | 7 mA per circuit at 24 VDC |
| Isolation Voltage | 500 VDC (field-to-logic) |
| Terminal Type | 3-position removable connectors |
| Power Draw | 150 mA at 5 VDC; 450 mA at 24 VDC |
| Dimensions | 13.2 cm x 7.0 cm x 7.6 cm |
| Weight | 0.68 kg |
| Storage Temperature | -40°C to +85°C |
| Operating Temperature | 0°C to +60°C |
Configuration Flexibility
The IC660BBD025 supports independent circuit configuration for each channel. You can designate each circuit as an input or output individually. This flexibility eliminates the need for separate I/O modules. Additionally, the block features selectable fault reporting on a per-circuit basis. The module uses two LED indicators per circuit for clear status indication.
Application Integration
This I/O block connects directly to the Genius bus through the integrated communication port. The block supports both isolated and non-isolated wiring configurations. Standard applications include conveyor controls, packaging equipment, and sorting systems. The high-density design conserves valuable cabinet space effectively. Furthermore, the block accommodates hot insertion for minimal system downtime.
Diagnostic Capabilities
Built-in diagnostics continuously monitor the health of every circuit. The block reports open-wire and short-circuit conditions automatically. It also performs self-tests during each scan cycle. These diagnostics reduce troubleshooting time considerably. The module stores fault information for later retrieval.
