The IC600KD516C operator interface delivers monitoring and control access for GE industrial automation systems. This panel combines a display screen with keypad entry and communication ports. Engineers rely on it for machine status viewing and process parameter adjustment on the factory floor.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Operator Interface Panel |
| Compatibility | GE Automation Controllers |
| Display Type | Backlit LCD, Multi-Line Character Display |
| Input Method | Membrane Keypad |
| Interface | Serial Ports, Backplane Connector |
| Dimensions | 240 mm x 160 mm x 60 mm |
| Weight | Approximately 1.05 kg |
| Component Count | 54 Active Electronic Components |
| Energy Storage | 3.0 V Lithium Backup Battery |
| Power Consumption | 24 VDC at 0.5 A |
| Operating Temperature | 0°C to 55°C |
| Relative Humidity | 5% to 95%, Non-Condensing |
Display and Control Design
The backlit LCD shows process values and alarm messages across multiple lines. Therefore, operators read critical data clearly in dim control rooms. Furthermore, the membrane keypad handles menu navigation and numeric entry tasks. Consequently, one panel covers both monitoring and configuration duties.
Interface and Communication
Serial ports link the IC600KD516C to controllers and peripheral equipment. As a result, data moves between the panel and host system without adapters. Additionally, a backplane connector supports direct rack integration where needed.
Power and Backup
The unit draws 24 VDC at 0.5 A from a standard industrial supply. Moreover, a 3.0 V lithium battery preserves parameter settings during outages. Consequently, technicians avoid re-entering values after brief power interruptions.
Installation Notes
Operators mount the panel through a standard cutout for flush fitting. The sealed front face resists dust and moisture in production areas. However, users should confirm cutout dimensions before drilling mounting holes.
Details
| Weight | 1.5 kg |
|---|---|
| Dimensions | 278 × 194 × 42 mm |
