The IC200PWB001D supports power distribution inside GE Fanuc’s VersaMax PLC platform as a booster carrier. This unit measures roughly 4.3 inches tall, 1.7 inches wide, and 2.4 inches deep. Moreover, it weighs about 0.4 pounds, so dense panel layouts stay practical. Engineers add the IC200PWB001D when power supplies need extra current capacity.
Technical Specifications and Interface Details
The carrier accepts a booster module and therefore extends available backplane current. Specifically, it mounts directly beside the main power supply on the DIN rail. Additionally, keyed connectors link the carrier to the VersaMax backplane. Status LEDs reveal power and fault conditions during service.
| Parameter | Specification |
|---|---|
| Module Type | Power Supply Booster Carrier |
| Platform | VersaMax PLC |
| Function | Extended backplane current |
| Dimensions | 4.3 x 1.7 x 2.4 in |
| Weight | ~0.4 lbs |
| Interface | VersaMax backplane |
| Indicators | Power and fault LEDs |
| Mounting | DIN rail |
Energy Storage and Output Stability
Internal capacitors on the IC200PWB001D provide local energy storage for stable booster output. Consequently, the carrier rides through brief supply dips without disturbing connected modules. This buffering also filters ripple that could affect analog measurements. The design therefore supports consistent performance across demanding plant conditions.
Installation and Compatibility Notes
Because the IC200PWB001D snaps onto standard DIN rail, technicians complete installation quickly. They should verify connector alignment before they apply power to the system. Furthermore, the carrier integrates smoothly with existing VersaMax power hardware. Always store spare units in anti-static packaging to protect sensitive components.
Details
| Weight | 1.5 kg |
|---|---|
| Dimensions | 278 × 194 × 42 mm |
