Compact Discrete Output for VersaMax Systems

This discrete output module provides reliable 24 V DC control for actuators and indicators. The IC200MDL330K offers 16 output points for flexible field device management. It operates as part of the VersaMax I/O platform, ensuring seamless integration with GE controllers. Each channel provides short-circuit protection for enhanced system reliability and safety. The module’s compact design supports high-density mounting in space-constrained cabinets.

Technical Specifications and Physical Attributes

The IC200MDL330K operates on a nominal 24 V DC supply from the backplane. It delivers 16 discrete outputs with a maximum current of 0.5 A per point. The module responds with an output delay of 1 ms for rapid control execution. It isolates outputs in groups of 8 for efficient circuit management and protection. The unit measures 117 mm in height, 69 mm in width, and 127 mm in depth. It weighs approximately 0.3 kg. Furthermore, the IC200MDL330K operates within a temperature range of 0 °C to 60 °C. Its built-in diagnostic LEDs provide real-time status monitoring.

Installation and Application Guidance

This output module drives solenoids, contactors, and indicator lights in automation systems. First, insert the IC200MDL330K into a free slot on the VersaMax rack. Then, connect the field wiring to the removable terminal block for quick installation. For inductive loads, always use appropriate suppression diodes across the outputs. Additionally, monitor the diagnostic LEDs for any fault conditions. The IC200MDL330K suits applications in packaging, material handling, and general machine control.
